IEC320 C13 Power PDU,19” cabinet , 8 way horizontal Power Distribution Unit
Model PE2L-08SSocket/Outlet Standard IEC320 C13
Outlet QTY 8 way
Power Input Style Left end single input style
Brackets Installation Style Frontal installation style
Cable plug IEC320 C20
Control functions
Protection functions Switch
Shell colour & Material White; Aluminium modular design
Cable specification 3*1.5mm2*3M; Standard 3 metre power cord
Electrical Rating 10A 250VAC
Maximum load current 10A Maximum load capacity 4KW
Size L*W*H 482.6*44.4*62mm
Relative humidity 10-90%
IEC320 C13 power distribution units are the standard choice in sever and networking 19” racks connecting directly to the targeted equipment, they are available as 10A to IEC320 C14 plug.
All PDU products of are modularized,customer can choose the relative modules and power input cables.
All functional modules are adopted PC/ABS alloy ,hot change temperature reach to above 120 degree,fire-retardant characteristic accords with UL94-V0 standard.
Ningbo Electric Pneumatic are the manufacturer of PDU sockts, IEC,FRENCH,USA,UK,GERMANY,ITALY standard power distribution sockets, and other electrical equipment items and crane parts.
